| 型号 |
6C |
8C |
10C |
12C |
| 进风口 |
D |
600 |
800 |
1000 |
1200 |
|
Φ |
650 |
850 |
1050 |
1250 |
| L1 |
110 |
110 |
110 |
110 |
| n1-d1 |
16-Φ10 |
20-Φ10 |
32-Φ10 |
40-Φ10 |
| 出风口 |
A |
420 |
570 |
715 |
840 |
| B |
480 |
640 |
800 |
960 |
| A1 |
470 |
620 |
765 |
890 |
| A2 |
520 |
670 |
815 |
940 |
| B1 |
530 |
690 |
850 |
1010 |
| B2 |
580 |
740 |
900 |
1060 |
| C |
25 |
25 |
25 |
25 |
| n2-d2 |
20-Φ10 |
28-Φ10 |
38-Φ10 |
48-Φ10 |
| 机壳 |
F |
460 |
600 |
710 |
850 |
| F1 |
380 |
510 |
640 |
830 |
| F2 |
550 |
730 |
950 |
1190 |
| E |
430 |
555 |
700 |
840 |
| E1 |
456 |
620 |
800 |
1000 |
| E2 |
720 |
925 |
1150 |
1370 |
| 机架 |
H1 |
180° |
570 |
740 |
980 |
1020 |
| 90° |
640 |
440 |
1110 |
1200 |
| 0° |
760 |
1000 |
1280 |
1480 |
| H2 |
80 |
90 |
125 |
125 |
| L2 |
400 |
500 |
635 |
750 |
| L3 |
550 |
650 |
835 |
1000 |
| V |
50 |
70 |
48 |
48 |
| H3 |
50 |
70 |
100 |
100 |
|
|
|
型号 |
6C |
8C |
10C |
12C |
|
风机底脚安装尺寸 |
M |
1250 |
1700 |
1976 |
2300 |
| M1 |
710 |
980 |
1256 |
1516 |
| M2 |
500 |
660 |
680 |
784 |
| M3 |
750 |
1040 |
1296 |
1556 |
| N |
900 |
1100 |
1420 |
1580 |
| N1 |
430 |
520 |
690 |
765 |
| N2 |
450 |
500 |
600 |
800 |
| N3 |
410 |
440 |
560 |
760 |
| N4 |
660 |
855 |
1040.5 |
1152 |
| C1 |
20 |
20 |
20 |
20 |
| n3-d3 |
8-Φ10 |
8-Φ18 |
8-Φ18 |
8-Φ18 |
| 地脚螺栓M2-1 |
M12×250 |
M16×320 |
M16×320 |
M16×320 |
| 垫片 |
δ |
3 |
3 |
3 |
3 |
| 备件 |
轴承GB286－64 |
3610 |
3612 |
3616 |
3617 |
| 轴承座CKS |
1610 |
1612 |
1616 |
1617 |
| 三角胶带型号 |
B |
B |
C |
C |
| 总量(Kg) |
210 |
350 |
460 |
720-1100 |
|
